    Stationary Concrete Batching Plant With Cement Silos 15 - 200 M3 Per Hour

    Ask Lasest Price
    Brand Name : Dongfeng Mid-south
    Model Number : HZS85
    Certification : CCC
    Price : USD 33,000 to 44,000 per set
    Payment Terms : T/T, L/C
    Supply Ability : 200 sets
    Delivery Time : 10 days
    • Product Details
    • Company Profile

    Stationary Concrete Batching Plant With Cement Silos 15 - 200 M3 Per Hour

    Stationary concrete batching with cement silos 15 to 200 m3 per hour


    Detail Parameters
    NoItemSpecificationQty.Remark
    1JS750 Concrete MixerMain Speed Reducer1Set
    Main Motor30KW1Set
    Oil supply system(Manual)1Set
    Liner and bladeAlloy1Set
    Overall Frame1Set
    lifting reducer1Set
    lifting Motor7.5KW1Set
    2PLD1600 Batching machine (three hoppers)Motor3KW4Set
    Measure HopperVolume 1.2m³1PCS
    Storage HopperVolume 2.5 m³3PCS
    3Water weighting systemMeasure Hopper200Kg1PCS
    Sensor500Kg3PCS
    Water Pump1.1KW1Set
    4Additive weighting systemMeasure boxVolume 30Kg1PCS
    Sensor50Kg3PCS
    Pneumatic butterfly valveφ65mm1PCS
    Pump0.55KW1PCS
    5Cement weighting systemMeasure Hopper400Kg1PCS
    Sensor500Kg3PCS
    Pneumatic butterfly valveφ300mm1PCS
    6Aggregate Supply System6M Screw conveyorΦ2192Set
    Motor11Kw2Set
    7Air systemPneumatic components1Set
    Air Compressor4KW1Set
    Pipe1Set
    8Standard Electric control systemElectric control cabinet1Set
    Main Component1Set
    Industrial Microcomputer19′1Set
    Color Display1Set
    9SiloEasy to assemble100T2PCS



    Terms of Condition
    Payment: 40% T/T in advance, 60% balance before shipment or L/C at sight.
    Deliver time: 10 days for shipment, 15 days for installation.
    Port of Loading: Qingdao Port, China
    Country of origin: China
    Warranty: 18 months once the plant has been installed
    Installation (Cost now included in FOB/CFR price)
    The seller should dispatches one technical to assist in installation, commissioning and training.
    The Visa, Round-Trip Flight Ticket and accommodation should be covered by the buyer.
    The salary of Engineer USD80/day/person should be paid by the buyer.
    The Buyer should get all necessary equipment for installation and provide translator.
    Package
    Concrete Mixing Plants and two silos are packed into two 40HQ.
