    Aluminum Semi Trailer Truck For Outdoor Advertising Hydraulic Lifting Stage

    Ask Lasest Price
    Brand Name : Dongfeng
    Model Number : DF13M
    Certification : ISO
    Price : 68500-70890
    Supply Ability : 200units per month
    Delivery Time : 1 month after payment
    • Product Details
    • Company Profile

    Aluminum Semi Trailer Truck For Outdoor Advertising Hydraulic Lifting Stage

    Mobile bike trailer for outdoor advertising


    Outdoor LED Display Advertising Vehicles


    13M stage semi trailer Specification
    ItemQuantityConfiguration list
    13m OEM semi trailer chassis1 unit10.00 steel tire,90 traction pin, ABS anti-lock system
    13m stage box1 set

    Stage length:12m

    Stage width: 6m

    Stage height:6m(maximinium)

    Firstly,both sides wing plates will be expanded by hydraulic power after four legs used to achieve vehicle stability.

    Secondly, a folding stage on the left and right sides is opened hydraulically.

    Finally, vehicle ceiling and both sides wing plates as stage ceiling, which are lifted and expanded by four vertical hydraulic cylinder of front and rear compartments.

    Vehicle hydraulic system1 set1 set of hydraulic power unit, 6 main and auxiliary stage cylinders, 6 wing panels, 4 support legs and 4 hydraulic cylinders on the ceiling.
    Electric equipment1 setTrailer box equipped with the distribution panel, lighting, lighting layout stage, power outlets, 220V power system set.
    Remote control equipment1 setVehicle hydraulic system using wireless remote control and a set of spare hydraulic manual operation device
    Vehicle painting1 set

    Raw material treatment:

    cutting, rust removal, grinding, phosphating, spraying anti-rust primer.

    Vehiclepaintingtreatment:

    spraying rust-proof primer, putty, polishing, spraying anti-rust primer, metal finish coating.



    • Factory direct sale, optional 1/2/3 sides full-color led screen, good visual effect.

    • Optional foldable stage with different sizes and multi-functional usage.

    • World famous chassis brand FAW, Foton, DFAC, JAC, ISUZU, Sinotruck, etc.

    • Widely used for outdoor commercial advertising, roadshows, product promotion.

    DFAC 4X2 led advertising truck ISUZU LED advertising truck JAC LED truck with screen lifting device


    Overall Dimensions: 7290×2330×3350mm 5995×2030×2980mm 5995×2020×3060mm


    Forland LED display truck Foton mini led display truck Foton Aoling led screen truck


    5995×2150×2900mm 5100×1710×2640mm 5995×2000×2900mm


    Sinotruck LED advertising truck FAW LED advertising truck Mobile led truck trailer with full color screen


    5995×2025×2995mm 5995×2030×2980mm Screen size can be customized
