3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck

    Buy cheap 3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck from wholesalers

    Buy cheap 3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck from wholesalers
    • Buy cheap 3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck from wholesalers
    • Buy cheap 3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck from wholesalers

    3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck

    Ask Lasest Price
    Brand Name : DONGFENG
    Model Number : DFST-1350
    Price : FOB China Port: USD14990~17990/unit
    Delivery Time : 10 work days
    Supply Ability : 2000units/year
    • Product Details
    • Company Profile

    3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck

    Dongfeng 3 Axle Low Bed Semi-Trialer-50 TON


    Advantages:


    1, Strong payload ability (Three units of FUWA 13Ton axle)

    2, Heavy duty and extra durability design.


    Specifications:

    DIMENSIONS
    Curb Weight8217kg
    Payload50,000kg
    G.V.W60,000kg
    Overall Length13000mm
    Overall Width3000mm
    Overall Height1050mm
    SPECIFICATION
    Main FrameHeavy duty and extra durability designed; Opting for high tensile steel Q345B, welding by automatic Submerged-Arc processes 505mm Height I beam, Top Flange 14mm,width 140mm; Middle Flange 6mm ; Bottom Flange 16mm,width 140mm
    FloorUpper limb:14mm; Lower limb:12mm; Plate:6mm
    AxleThree Units of FUWA 13 Ton axle
    SuspensionA couple of German Style mechanical 3-axle suspension
    Leaf SpringEight sets of reliable local brand, 10-piece leaf spring
    King PinOne unit of 2`` kingpin
    Landing GearTwo-speed , manual operating, heavy duty landing gear
    Wheel RimTwelve units of 8.0-22.5 rim
    TyreTwelve units of Triangle 12R22.5 tyre
    Twist LockEight nos. of ISO twist lock for 2x20ft;1x40ft container, the central locks can be laid down.
    Spare Wheel CarrierOne set of spare wheel carrier including a riser.
    Pneumatic Braking SystemTwo units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; two units of T30 brake chamber two units of reliable local brand 40L air tank ; two units of reliable local brand standard coppery air-connector.
    Electrical SystemOne unit of JAEGER POWAY ,24V 7-pin ISO 1185 socket; Tail lamp with turn signal, brake light & reflector , Side lamp etc.
    One set of DAFA(brand ) 6-core standard Cable.
    PaintingSand blasting processing clean rust
    One coat of anticorrosive primer
    Two coats of finish urethane paint
    Color as customer choice
    Accessory

    One tooling box with a set of standard trailer tool


    Picture:


    3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck

    Quality 3 Axles FUWA Heavy Duty Semi Trailers 13000mm Length Cement Carrier Truck for sale
