Dongfeng chassis Concrete Mixer Truck from 3 cbm to 16 cbm

Product Categories

Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.

Contact Now

Name: Dongfeng chassis Concrete Mixer Truck from 3 cbm to 16 cbm
Brand: Dongfeng
Price: 30000 USD

Add to Cart

Concrete Mixer Truck With Dongfeng Chassis 12 cbm Loading Capacity

Dongfeng chassis Concrete Mixer Truck from 3 cbm to 16 cbm

Drive mode	6×4
Engine	Model	L340 30
	Type	6-cylinder in line, turbocharging and inter cooling, mechanical injection pump, bulit-in EGR
	Max. power(Kw/rpm)	250/2200
	Max. torque(N.m/rpm)	1350/1400
	Displacement(ml)	8900
	Type of fuel	Diesel
	Compression ratio	(16.6±0.5):1
Cab	D310-S1	single berth
Gearbox	Model	9JS150T-B
Gearbox	Max.torque(N.m)	1500
Clutch	Φ430mm	diaphragm spring clutch
Frame Height×Width× Thickness(mm)	300×90×(8+6)
Frame Height×Width× Thickness(mm)	Frame width 940 (front ), Frame width 810 ( rear )
Tyre	Size	11.00-20
Air conditioner	A/C
Dimensions	Overall dimension (mm)	10520×2500×3990
	Wheel base (mm)	4000+1350
	Front/Rear tread(mm)	2027/2027,1820/1820
	Appr./Depa. angel (°)	25/20
	Min. ground cleanrance(mm)	250
Mass	Payload(Kg)	16565
	Curb weight(Kg)	14305
	G.V.W(Kg)	31000
Performance	Max. speed(Km/h)	85
	Max. gradeability(%)	40
	Min. turning diameter(m)	20
	Fuel consumption(L/100Km)	38
Special function	Mixing capacity(m³)	12
	Angel of inclination of mixing drum(°)	13
	Geometric volume(m³)	12
	Filling ratio(%)	58
	Feeding speed(m³/min)	≥3
	Discharge speed(m³/min)	≥2
	Residual ratio(%)	＜0.8
	Collapsed degree range(mm)	40-230
	Hydraulic pump	MA4VG90, Italy
	Hydraulic motor	MF090W, Italy
	Decelerator	577L3131AX1A, Italy
